2000W 24V 60A/36V 40A/48V 35A/60V 26A/72V 20A Electric Car/Forklift/Stacker Traction Battery High Power Industrial Fast Charger

High Power Industrial Fast Charger for Electric Car/Forklift/Stacker Traction Battery. Factory direct, efficient charging for various voltage systems.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
UV-GN-20
Shell Material
Aluminium
Transport Package
Seaworthy Packing
Specification
320*290*90mm
Trademark
DK
Origin
China
HS Code
85044099
Production Capacity
2, 000, 000 PCS / Year

Product Description

Intelligent Li-ion Battery Charger- UV-GN-20 2000W Series

2000W 24V 60A/36V 40A/48V 35A/60V 26A/72V 20A Electric Car/Forklift/Stacker Traction Battery High Power Industrial Fast Charger



APPLICATION:

All types of lithium batteries and new energy maintenance-free batteries are applied in the electric mobilities, such as:
Electric scooter/tricycle/balance bike/golf cart/drone/sweeper/robot/AGV/forklift/boat and so on.
2000W 24V 60A/36V 40A/48V 35A/60V 26A/72V 20A Electric Car/Forklift/Stacker Traction Battery High Power Industrial Fast Charger




CHARGING PRINCIPLE:

Two-transistor forward, 3-phase PID Controlling Intelligent Charging
2000W 24V 60A/36V 40A/48V 35A/60V 26A/72V 20A Electric Car/Forklift/Stacker Traction Battery High Power Industrial Fast Charger
Automatically stop after charge fully



CHARING CURVE:

2000W 24V 60A/36V 40A/48V 35A/60V 26A/72V 20A Electric Car/Forklift/Stacker Traction Battery High Power Industrial Fast Charger


Remarks: The specific charging curve for the lead-acid battery is available to customize upon the requirement.




General Specification:

Model No.:UV-GN-20
Rated Volt Input Volt
(AC)
CC Lead Acid Ternary Polymer Li-ion LiFePo4
CV CV Strings CV Strings
12V 185-265V
/90-135V

50/60HZ
60A 14.70V 12.60V 3S 14.60V 4S
16.80V 4S 18.25V 5S
24V 50A 29.40V 25.20V 6S 29.20V 8S
29.40V 7S 32.85V 9S
36V 35A 44.10V 42.00V 10S 40.15V 11S
46.20V 11S 43.80V 12S
48V 30A 58.80V 54.60V 13S 54.75V 15S
58.80V 14S 58.40V 16S
60V 26A 73.50V 67.20V 16S 69.35V 19S
71.40V 17S 73.00V 20S
72V 20A 88.20V 84.00V 20S 83.95V 23S
88.20V 21S 87.60V 24S
Mechanical characteristic:

Shell material: Aluminum
Dimension: L*W*H= 320*290*90mm
Input socket: meets IEC standard
AC wires: 1.2m length
DC wires: 1.2m length
Net Weight: 4.5 Kgs




FEATURES:
Circuit and Hardware
* High-performance circuit with all-digital switching power supply design, the stability and consistency of the product is excellent.
* Fast response hardware protection of over-current, over-voltage, and reverse connection.
* Three digital temperature control sensors monitor the internal and external temperature of the charger in real-time.
* Complete protection function covering: Over-Temperature, Reverse Connection, Short-Circuit, Under-Voltage, Over-Voltage. Abnormal State Auto-recovery.
* Low power consumption design, the power of no-loading5W.
* Communication Interface: Can, RS485, UART, or other interfaces at optional.
* Led indicator lights display working status, charging power, and fault status in real-time

Rich Software Function
* All-digital microcomputer intelligent detection and control system, fast response speed and accurate curve control.
* Double-loop cascade PID controls the charging current and voltage, and the charging curve control is flexible and precise.
* Innovative fault self-checking function.
* Charging self-learning function, adjust the charging parameter according to the battery condition.
* Power-off memory function, abnormal state auto-recovery.
* Conform to the charging characteristic curve of various batteries.
* Supporting online upgrade and remote communication, optional functions such as Lock, Charge Control, JTAG and DEBUG .

Efficient heat-dissipating structure design

* Compact design with a lightweight, easy to use
* CGS fan cooling technology and unique internal structure design allow heat to be quickly discharged and enhance stability.
* Durable Aluminum shell design with excellent heat dissipation.

2000W 24V 60A/36V 40A/48V 35A/60V 26A/72V 20A Electric Car/Forklift/Stacker Traction Battery High Power Industrial Fast Charger



2000W 24V 60A/36V 40A/48V 35A/60V 26A/72V 20A Electric Car/Forklift/Stacker Traction Battery High Power Industrial Fast Charger




2000W 24V 60A/36V 40A/48V 35A/60V 26A/72V 20A Electric Car/Forklift/Stacker Traction Battery High Power Industrial Fast Charger



PACKING

2000W 24V 60A/36V 40A/48V 35A/60V 26A/72V 20A Electric Car/Forklift/Stacker Traction Battery High Power Industrial Fast Charger


About us:

Founded in 2005, DEKANG is a high-tech enterprise involved in researching & developing, production and sales of Storage Battery Detection Equipment, Intelligent Charger, Charging Station, Shared Mobility Solutions. We provide the clients with the complete solution of storage batter service.

Products Category:
Battery Charging & Discharging Detector
Battery Detection and Recovery Equipment
Intelligent Charger

E-Bike/E-scooter Charging Station
Shared Battery Charging & Swapping System
Intelligent Lithium Batteries
Battery-swapping E-bike/E-scooter and so on.


Why choose us?
  1. Beginning from 2005, we have achieved the leadership of our industrial
  2. Over 15 years of experiences
  3. Powerful function and superior performance
  4. Professional and strong R&D team.
  5. Technical leadership and advantage
  6. Advanced production technology and automatic assembly line
  7. Market verification and specialized users' approval from over 50 countries
  8. Rich experience in market operation
  9. Professional after-sale service, lifelong after-sale service provided


Delivery
Sample order dispatched by express via DHL, FEDEX, TNT, UPS or any other express services you prefer to, also we can coordinate to send it to other agreed address in China for loading with your convenience


Normal order delivered by sea or air as per your instructions.

Warranty:
12-month warranty, lifelong after-sale service, and free technology service.


After-sales service
Free replacement parts will be provided during the warranty period, and we will dispatch the replacement parts to the user by DHL, UPS, TNT, or FEDEX at our account and guide the user to replace via phone, email, or video.

After the warranty period, the cost of replacement parts will be charged. If you pay for the replacement parts, you can enjoy free warranty within half a year from the maintenance date for the same problem.

Lifelong free technology service provided by us, the users can advise malfunction and inquire the maintenance technology through the telephone, fax, email, and social media, etc.

Paid service
The conditions below are not included in the free maintenance range, the company provides the paid service, kindly note:
  1. Do not operate or use as per the manual and cause the damage
  2. The instrument was disassembled or repaired by the non-authorized person by our company
  3. Unexpected factors or man-made causes the damage, such as the water inflowing, mechanical damage, falling, burning, and so on.

2000W 24V 60A/36V 40A/48V 35A/60V 26A/72V 20A Electric Car/Forklift/Stacker Traction Battery High Power Industrial Fast Charger
