Factory Direct Sales AC Plug Customizable 120V 240V 11kw EV Charger Portable Car Battery EV Charger 3.3kw on Board

Get the Factory Direct Sales AC Plug Customizable 120V 240V 11kw EV Charger Portable Car Battery EV Charger 3.3kw on Board for your electric vehicle. We are a factory providing quality charging solutions.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
BNEVAM2
Charge Method
Normal Charge
Rated Current
6A/8A/10A/13A/16A/32A
Output Power
3.5kw/7kw/11kw/22kw
Input Voltage
110V/220V/380V
Plug
Schuko/NEMA6-20/Blue Cee/ British Specification Pl
Certificate
CE/TUV/RoHS
Material
Plastic/Aluminum
Product Name
Portable EV Charger
Type
Type1/Type2
Transport Package
Cardboard Box
Trademark
BANNA
Origin
China
HS Code
8504409999
Production Capacity
2000

Packaging & Delivery

Package Size
445.00cm * 330.00cm * 130.00cm
Package Gross Weight
6.000kg

Product Description

BANNA Hot selling Portable Electric Car Home Use Charger 6~16A Adjustable Current 3.5KW Applicable to Most Electric Vehicles
Factory Direct Sales AC Plug Customizable 120V 240V 11kw EV Charger Portable Car Battery EV Charger 3.3kw on Board
Model KFEVAM2-07K KFEVAM2-11K KFEVAM2-22K
Technical Data
Power Up to 7kW Up to 11kW Up to 22kW
Voltage 230VAC±20% 400VAC±20% 400VAC±20%
Rated current 32A 16A 32A
RCD Type A(AC:30mA)+DC:6mA
Frequency 50/60Hz
Standby power <3W
User interface 2.4''LED display, Setting button, Status LEDs
Certificate/Compliance CE / EN/IEC 61851-1:2017, SAE J1772
Charging Interface Type1/Type2 Plug,
Special Protection Short circuit protection, Leakage current protection, Input Wiring Defect, Over current protection, Ground protection, Over/Under voltage protection, Over temperature protection

Physical properties
Warranty 1 years
Protection Ip66
Control box material Aluminum alloy
Cooling Natural cooling
Operating temperature -30 °C to +55°C
Humidity Max.95%(non-regulating)
Net Weight 3.3kg 3.1kg 4.6kg
Gross Weight 4.2kg 4.0kg 5.5kg
