12V 6A Car Battery Charger 12V 3-Stage AGM Lead Acid Battery Charger

Get reliable and efficient 12V 6A Car Battery Charger 12V 3-Stage AGM Lead Acid Battery Charger from our factory. Ensure optimal performance and durability.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
  • Detailed Photos
  • Packaging & Shipping
  • Company Profile
  • FAQ
Overview

Basic Info.

Model NO.
TK-300
Nominal Voltage
12V
Charger Style
Pulse Charger
Compatible Battery Type
12-Volt
Size
DC;AC
Certification
PSE, RoHS, CE, FCC;Ukca
Socket Type
For E.U.
Recyclable
Non-Recyclable
Input Voltage
100-240VAC,50-60Hz
Power
96W
Minimum Start Voltage
6V
Battery Range
4-100ah
Output
12V DC,5-6A
Efficiency
85%
Standard
CE,Ice60335,En61000,En55014
Material
ABS
Weight
0.43kg
Protection
Output Short,Short Circuit,Overvoltage,Overcurrent
Packaging
30/50PCS Per Box
Plug
Au/EU/UK/Us/Jp
Color
Yellow;Green;Blue
Warranty
1 Year / 12 Months
Advantage
Fully Automatic
Transport Package
Carton Packaging
Specification
150(L)*82(W)*63(H)mm
Trademark
E-FAST
Origin
China, Anhui
HS Code
8504409999
Production Capacity
50, 000 Pieces Per Month

Product Description

Product Description


12v 6a Car Battery Charger 12v 3-stage agm lead acid battery charger

1.Product parameters
Brand Name: E-FAST
Model Number: ZYX-TK300
Input voltage and current: 100-240VAC(50/60Hz)
100VAC/1A, 240VAC/0.5A
Power 96W
output voltage and current: 12V 6A
Battery Range 4-100AH
Battery Type 12V STD;Lead-acid ;AGM ;GEL ;WET ;EFB Battery
Color Yellow;Red
Material ABS
Dimension 150(L)*82(W)*63(H)mm
Weight 0.430KG
Applications Car;Motorcycle;boat;Vehicle;truck for 12v lead acid battery
Certification CE;PsE;RoHS;FCC;UKCA
Protection
-Polarity protection
-Output short protection
-Short circuit protection
-Overvoltage protection
-Overcurrent protection
-Overheating protection
-Reverse connection protection
Plug AU/EU/UK/US/JP
Efficiency 85%

2.Product Function
(1) Output short circuit and anti reverse connection: The product has a prompt for output short circuit and reverse connection of the battery (reverse connection 1-2S detection, when reverse connection or short circuit is detected, the LCD displays "ERO", and the product will not be damaged due to reverse connection or short circuit during the detection process), and during reverse connection, there will be no reverse connection spark phenomenon after processing by a microprocessor program;

(2) Battery power detection: Without connecting to the AC input voltage, the battery clip is sandwiched between the positive and negative electrodes of the battery (red, positive, black, negative), and the current and voltage parameters of the battery can be displayed (digital tube display data: voltage and ambient temperature cycle display, the power grid is displayed in percentage form based on the detected data, the first power on 6S self check wait, 6S not reached only display temperature, 6S reached temperature and voltage cycle display)

(3) Winter/Summer Mode: During the charging process, detect the ambient temperature, adjust the charging state of the product in a timely manner, and ensure battery life and charging safety. Winter Mode: LCD displays snowflakes, Summer Mode: LCD displays the sun (unique to car mode, not available in other modes)

(4) Over temperature protection: The product has an over temperature protection function. If the product detects excessive temperature, it will automatically start the over temperature protection program. When the temperature returns to normal, the initial charging state will be restored

(5) Overcharge protection: The product has an overcharge protection function to prevent overcharge from reducing the battery life and enhancing the reliability of charging safety (the maximum charging duration is 15.5-16.0H by default)

(6) Battery charging progress bar: The charging progress bar is displayed during the charging process of the product, in the form of a percentage, and the full charge display is 100%

(7) LCD display status:
a: Full state: LCD displays "FUL"
b: Clip disconnection mode: LCD displays "OFF"
c: Fault mode: LCD displays "ERO"
e: Charging state: LCD circularly displays voltage, current, and charging progress
f: Repair mode: LCD displays "PUL", and the repair icon flashes
h: Repair completed: LCD display "FUL" repair icon is always on
g: Detect battery power: LCD cycle displays voltage, and battery power is displayed as a percentage


3.Product function mode selection:
(1) Car battery charging mode
a: Charging current: Imax: 5.5A@DC12V pattern
b: Charging voltage: DC14.4-14.9V@DC12V pattern;
c: Battery type: DC12V lead-acid battery
d: Maximum single charge duration tmax: 15-16H
e: Float charging voltage: DC13.8V

(2) AGM/GEL battery standard mode
a: Charging current: Imax: 5.5A@DC12V pattern
b: Charging voltage: DC14.6V@DC12V pattern;
c: Battery type: DC12V lead-acid battery
d: Maximum single charge duration tmax: 15-16H
e: Float charging voltage: DC13.8V

(3) Motorcycle charging mode
a: Charging current: Imax: 1.5A@DC12V pattern
b: Charging voltage: DC14.6V@DC12V pattern;
c: Battery type: DC12V lead-acid battery
d: Maximum single charge duration tmax: 15-16H
e: Float charging voltage: DC13.8V

(4) Lead acid battery repair mode
a: Repair principle: positive pulse voltage repair mode
b: Repair voltage: DC14.6V@DC12V pattern; DC29.2V@DC24V pattern
c: Battery type: lead-acid type battery
d: Maximum repair time tmax: 15-16H
e: Floating charge voltage: no floating charge



3.Charging Steps
(1) Clamp the output alligator on both ends of the battery, red positive and black negative
(2) Insert the charger AC input line into the socket, and then turn on the socket switch
(3) Select the charging mode and then charge it
(4) When the charger displays "FUL", it indicates that the charging mode has ended. At this time, disconnect the AC input. After 10s, observe the battery capacity status (LCD cycle displays voltage and battery power). After confirming that it is fully charged, disconnect the alligator clip from the battery.




Detailed Photos

Charging stepsChar

12V 6A Car Battery Charger 12V 3-Stage AGM Lead Acid Battery Charger

12V 6A Car Battery Charger 12V 3-Stage AGM Lead Acid Battery Charger12V 6A Car Battery Charger 12V 3-Stage AGM Lead Acid Battery Charger

12V 6A Car Battery Charger 12V 3-Stage AGM Lead Acid Battery Charger

Packaging & Shipping

Package specification30/50pcs/Carton

Color Box size22*11*6.5cm


Delivery Detail: sample within 7 work days,15~25 days for bulk order

Company Profile



Tianchang Zhiyun Electronic Technology Co., Ltd


Professional battery charger manufacturer



Tianchang Zhiyun Electronic Technology Co.,Ltd.,is a technological innovation enterprise specializing in the research and development, production, and sales of electronic products such as battery chargers, power supplies, etc. The company is located in Tianchang City, Anhui Province,covering an area of 1000 square meters,having a variety of advanced production equipment.

The company's independent flagship brand E-FAST has multiple models of products, including ZYX-J10 (12V6A); ZYX-J20(12V7A); ZYX-J30 (12V8A 24V4A);ZYX-J40(12V6A 24V3A); ZYX-J50(12V10A24V5A);ZYX-J99(6V/12V2A); TK100(batteryTester);TK300(12V6A); TK400(12V6A); TK500(12V12A 24V6A); TK700 (12V10A 24V5A), mainly suitable for lithium batteries, lead-acid batteries, AGM and GEL batteries, WET batteries,Start stop batteries,etc.

The company also has 36V 48V 60V 64V 72V 84V 96V 12AH 20AH 32AH 38AH 45AH 52AH and other models of lead-acid battery chargers for electric vehicles, electric bicycles, Car,motorcycles, and scooters.

In addition, the company has ternary lithium batteries and iron lithium battery chargers of models such as 24V, 36V, 48V, 60V, 72V, 2A, 3A, 5A, 10A, 12A, 15A, 18A, 30A, 20-30A, 25-35A, 40-60A, etc.

In short, we can offer various types of battery chargers with a wide range of coverage. I specialize in wholesale and can provide you with a variety of customized services, including product appearance, colors, and logos. If the customer chooses us, we promise that you will enjoy preferential policies such as minimum order quantity, free samples and large discounts.

12V 6A Car Battery Charger 12V 3-Stage AGM Lead Acid Battery Charger



12V 6A Car Battery Charger 12V 3-Stage AGM Lead Acid Battery Charger
