3.3kw EV Charger IP67 Air Cooling Battery Obc on Board Charger Electric Car Charger

Get reliable and efficient 3.3kw EV Charger IP67 Air Cooling Battery OBC on Board Charger from our factory. The perfect solution for electric car charging.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Specification
  • Company Profile
  • Certifications
  • Customer′s Feedback
  • Packing
  • FAQ
Overview

Basic Info.

Model NO.
EVPT23-
Control Method
Can Bus Control/Enable
Mating Connectors Kits
Provided Free
Power
3.3kw
Efficiency
94%
Voltage Level
48V 72V 96V 144V 312V 540V
After-Sales Service
24 Hours Online
Type
Slow EV Charger
Certification
CE, ISO, RoHS
Warranty
24 Months
Protection Grade
IP67
Customization
Yes
MOQ
1PCS
Mating Connector
We Offer Mating Connector
Transport Package
Carton
Specification
22.3*11*13.1cm
Trademark
EVPT CHARGER
Origin
China
HS Code
8504409992
Production Capacity
500000PCS/Year

Packaging & Delivery

Package Size
22.30cm * 11.00cm * 13.10cm
Package Gross Weight
5.400kg

Product Description

3.3kw EV Charger IP67 Air Cooling Battery Obc on Board Charger Electric Car Charger

Specification



3.3KW On Board Charger for EV

Model
OBC Max Output V/A
Rated Voltage
OBC Power
Cooling Method
EVPT23-4840
68V/40A
48V
3.3KW
Forced Air Cooling
EVPT23-7240
101V/40A
72V
3.3KW
Forced Air Cooling
EVPT23-9632
132V/32A
96V
3.3KW
Forced Air Cooling
EVPT23-14423 198V/23A 144V 3.3KW Forced Air Cooling
EVPT23-32010
430V/10A
320V
3.3KW
Forced Air Cooling
EVPT23-54006 650V/6A 540V 3.3KW Forced Air Cooling

Contact seller to get specific datasheet and 3D STEP model

AC Input Voltage Range AC90V - AC264V
Rated Voltage 32 - 650VDC
AC Input Frequency 45 - 65 Hz
AC Power Factor ≥ 0.98
Full Load Efficiency ≥ 93%
Environmental Enclosure IP67
Ambient Temperature -40ºC - +55ºC
Storage Temperature -40ºC - +100ºC
Control Method With Can Bus/Enable Wire

3.3kw EV Charger IP67 Air Cooling Battery Obc on Board Charger Electric Car Charger
Matching Connectors


Connector details display, supporting different types of connectors, please contact our technical sales staff for additional connector models

3.3kw EV Charger IP67 Air Cooling Battery Obc on Board Charger Electric Car Charger3.3kw EV Charger IP67 Air Cooling Battery Obc on Board Charger Electric Car Charger

3.3kw EV Charger IP67 Air Cooling Battery Obc on Board Charger Electric Car Charger
Professional Specification Drawing.


We have a series of professional files of DCDC converter, Such as 2D parameter drawing, 3D STEP model, is to ensure that our product is suitable for your vehicle.


Due to it is related to business secrets. Please contact sellers to get specific datasheet!
Application Scenarios.


Our On Board Charger have exported to more than 20 countries and regions. Such as India, Germany, USA, UK, Australia and so on. With a widely praised.

It can be used for electric forklift, new energy vehicle, golf cart, lawn power, street sweeper, boat, RV, SUV, electric aircraft, EV conversion and so on.
3.3kw EV Charger IP67 Air Cooling Battery Obc on Board Charger Electric Car Charger



Company Profile



3.3kw EV Charger IP67 Air Cooling Battery Obc on Board Charger Electric Car Charger 3.3kw EV Charger IP67 Air Cooling Battery Obc on Board Charger Electric Car Charger
3.3kw EV Charger IP67 Air Cooling Battery Obc on Board Charger Electric Car Charger

Certifications



3.3kw EV Charger IP67 Air Cooling Battery Obc on Board Charger Electric Car Charger

Customer's Feedback



3.3kw EV Charger IP67 Air Cooling Battery Obc on Board Charger Electric Car Charger


Packing

3.3kw EV Charger IP67 Air Cooling Battery Obc on Board Charger Electric Car Charger
Packing Method: Delivery Method:
1. Foam+ Box+ Carton+ Wooden frame. By air, sea or land according to customer's choice.
2. Foam + Color box + Carton.
3. As per clients require. Loading Port:
  Shanghai port or other port you want.
Shipping Time:
About 15-30 days for small quantity. Guarantee:
About 45-60 days for large quantity. 1 Year.


FAQ

Q: Can you guarantee the quality with such a low price? A: We have signed a long-term strategic cooperation agreement with battery manufacturers. All the prices are the lowest in the market, and cell consistency is good. We buy a lot at one time, so the price is very competitive.

Q: Can you provide inspection report when delivery? A: We can provide the manufacturer's test report and the original purchase contract.

Q: How do you transport lithium batteries? A: We have professional freight forwarding and export qualifications. We can ensure that the goods are received within 15-20 days after payment is received.

Q: How are your batteries after sale? A: We have a 10-year R&D experience of professional and technical team, can remote guidance or help customers solve problems on the spot.

Q: What's the MOQ for lithium batteries? A:We Support small order as one piece.

Contact us

Please feel free to give your inquiry in the form below We will reply you in 24 hours
