China Factory 5kwh 10kwh 24V 48V 100ah 200ah 300ah 400ah Lithium Ion Lipo Li Ion 48V LiFePO4 Lithium Storage Solar Battery for Home Solar Energy Storage

Get high-quality, affordable 5kwh-400ah lithium ion solar batteries for home energy storage from our China factory. Buy 24V/48V LiFePO4 storage solutions.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
  • Our Advantages
  • Company Profile
  • Packaging & Shipping
Overview

Basic Info.

Model NO.
Lithium battery
Size
Medium
Certification
Un38.3/MSDS/CE/TUV/IEC
Logo OEM
Yes
Voltage
51.2V
Capacity
100ah, Expandable
Sizes
442*435*155mm
Weight
48kg
Lifespan
6000 Cycles
Design Life
15 Years
BMS
RS485/232/Can
Application
UPS, Solar Energy Storage System
Installation
19 Inch Rack
Display
LED Display
Assembly
16s1p
Expandable
32PCS in Parallel
Key Works
Lithium Battery
Transport Package
Carton and Pallet
Specification
LiFePO4
Trademark
OEM
Origin
Hunan, China
HS Code
8507600090
Production Capacity
5000 Sets/Month

Packaging & Delivery

Package Size
60.00cm * 60.00cm * 30.00cm
Package Gross Weight
60.000kg

Product Description





China Factory 5kwh 10kwh 24V 48V 100ah 200ah 300ah 400ah Lithium Ion Lipo Li Ion 48V LiFePO4 Lithium Storage Solar Battery for Home Solar Energy Storage
China Factory 5kwh 10kwh 24V 48V 100ah 200ah 300ah 400ah Lithium Ion Lipo Li Ion 48V LiFePO4 Lithium Storage Solar Battery for Home Solar Energy Storage
1 .Compatiable with various inverter brands, Growatt, Luxpower, Solis, Socolar, Victrons, Deye
2. Support max 64pcs in parallel, which is equals to 48v 6400ah, meet all different house demands.
3. Features 99% Operating Efficiency vs 80% for AGM batteries. An equivalence of adding 20% additional solar panels to your current system.
4. A+++ Cells with 6000cycles 80%DOD, 15 years of use even if you deep discharge it every day.
5.  Plug and play,  providing all installing material, easy and quick.
6. All Cells are bolted together with heavy plates and ABS holder for very reliable connections internally
7. RS485 and CAN on from panel with RJ45 port, plug and play.

Product Description


China Factory 5kwh 10kwh 24V 48V 100ah 200ah 300ah 400ah Lithium Ion Lipo Li Ion 48V LiFePO4 Lithium Storage Solar Battery for Home Solar Energy Storage Three modules available
MODEL
CTS4850R
CTS48100R
CTS48200R
ELECTRICAL SPECIFICATIONS
Cell Type - Chemistry
LiFePO4
LiFePO4
LiFePO4
Rated Capacity
50Ah
100Ah
200Ah
Rated Voltage
51.2V
51.2V
51.2V
Energy
2.56kWh
5.12kWh
10.24kWh
MECHANICAL SPECIFICATIONS
Dimensions (L x W x H)
442*410*133mm
442*435*155mm
442*820*155mm
Weight
28Kg
48Kg
82Kg
DISCHARGE SPECIFICATIONS
Discharge Cut-off Voltage
40V
40V
40V
Max Continuous Discharging Current
50A
100A
150A
Recommended Disharge Current
25A
50A
100A
CHARGE SPECIFICATIONS
Charging Limited Voltage
57.6V
57.6V
57.6V
Max Charging Current
50A
100A
150A
Recommended Charge Current
25A
50A
100A
Working Temperature Range
Charge: 0~45ºC
discharge : -20~60ºC
Recommended Operating Temperature
15~35ºC
Recommended Storage Temperature & Humidity Range
15~35ºC, 45~75%RH


Those modules support in parallel connection from 48v 50ah to 48v 3200ah

Meet the power consumption of different houses
China Factory 5kwh 10kwh 24V 48V 100ah 200ah 300ah 400ah Lithium Ion Lipo Li Ion 48V LiFePO4 Lithium Storage Solar Battery for Home Solar Energy StorageChina Factory 5kwh 10kwh 24V 48V 100ah 200ah 300ah 400ah Lithium Ion Lipo Li Ion 48V LiFePO4 Lithium Storage Solar Battery for Home Solar Energy Storage
China Factory 5kwh 10kwh 24V 48V 100ah 200ah 300ah 400ah Lithium Ion Lipo Li Ion 48V LiFePO4 Lithium Storage Solar Battery for Home Solar Energy Storage How to connect batteries with the inverter and MPPT

China Factory 5kwh 10kwh 24V 48V 100ah 200ah 300ah 400ah Lithium Ion Lipo Li Ion 48V LiFePO4 Lithium Storage Solar Battery for Home Solar Energy Storage

Our Advantages


Five exclusive designs

China Factory 5kwh 10kwh 24V 48V 100ah 200ah 300ah 400ah Lithium Ion Lipo Li Ion 48V LiFePO4 Lithium Storage Solar Battery for Home Solar Energy Storage

China Factory 5kwh 10kwh 24V 48V 100ah 200ah 300ah 400ah Lithium Ion Lipo Li Ion 48V LiFePO4 Lithium Storage Solar Battery for Home Solar Energy Storage

CTS
Other
Plastic holder
1.We use customized plastic holder between each cells for better insulation, so when the operator install batteries, there will be no danger
No holder between cell, insulation need to be concerned
Top extension
2.There is an extension at the top of the bracket. When there is a shock or heavy drop or vibration, battery itself will not be the first to bear the brunt
Have a metal top extension in the first one, no top extension in the second
Unblocked explosion-proof valve
3.The explosion-proof valve is not blocked, the physical structure safety of the cell is ensured
Both has blocked explosion-proof valve, not meet the cell safety using requirements
BMS with cover
4.BMS is well protected by metal cover, prevent damage for shock
No cover on both BMS
Laser welding+Screws
5. We use laser welding around the srew to further strengthen the connection to completely eliminate the risk of screw falling. Laser welding also reduce the contact surface between the screw and the bus bar to enhance current capability. This laser welding can also reduce internal resistance and reduce power consumpution. The user can get more power
First has untidy welding, big risk of damage cables, second only srews.
Orderly cable arrangement
6. Orderly cable arrangement can reduce poor connector contact, short circuit and open circuit between wires
lack of standardization, cables go through basbar in the first, disorder cables in the second



Company Profile


China Factory 5kwh 10kwh 24V 48V 100ah 200ah 300ah 400ah Lithium Ion Lipo Li Ion 48V LiFePO4 Lithium Storage Solar Battery for Home Solar Energy Storage
10+ years to sharpen a sword.
We do only one thing, professional customization.

20 + R&D team
150 front-line production employees
10 production lines
20,000 square meter plant
Capacity up to 500mwh


Since 2011, CTS has focused on one-stop customization of lithium battery products such as electric vehicle batteries, large energy storage batteries, smart home storage batteries, high-end electric motorcycle batteries and so on.

We have more 30 types of cells, and could make OEM battery pack from 12v-800v, 10-200ah, which can be used in electric vehicle, E-bike, UPS, energy storage system, telecommunication base station,E-scooter, E-tools,unmanned airplane, golf cart, fork lift, cleaning car , electric wheelchair, etc.

We has been pursuing quality policy of continuous innovation and improvement to meet customer's requirements. To realized full automation, we has introduced advanced foreign equipment and technology from Korea and Germany. To ensure the best quality, we has passed I S O 9 0 0 1 , I S O 1 4 0 0 1 and O H S A S 1 8 0 0 1 certifications.

We stick to the company concept of human orientation and efficient innovation and we welcome customization. So, lets join together to promote the development of renewable energy and friendly environment.

China Factory 5kwh 10kwh 24V 48V 100ah 200ah 300ah 400ah Lithium Ion Lipo Li Ion 48V LiFePO4 Lithium Storage Solar Battery for Home Solar Energy Storage


Packaging & Shipping

1. Hard carton and foam packaging, safe for different shipment 2. 100% full inspection before shipment to ensure quality control 3. MSDS and UN38.3 certifications to ensure customs declaration and clearance during transportation 4. Customs on-site inspection to ensure the safety of the battery

China Factory 5kwh 10kwh 24V 48V 100ah 200ah 300ah 400ah Lithium Ion Lipo Li Ion 48V LiFePO4 Lithium Storage Solar Battery for Home Solar Energy Storage

Customers feedback

China Factory 5kwh 10kwh 24V 48V 100ah 200ah 300ah 400ah Lithium Ion Lipo Li Ion 48V LiFePO4 Lithium Storage Solar Battery for Home Solar Energy Storage


Contact us

Please feel free to give your inquiry in the form below We will reply you in 24 hours
