12V/24V 60A 7 stage  Automatic Car RV battery Charger  for AGM GEL WET Rechargeable  Battery Charger

Get reliable 12V/24V 60A 7 stage Automatic Car RV battery Charger for AGM GEL WET Rechargeable Battery from our factory. Shop now for quality charging solutions!
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
EBC12/24-60
Transport Package
Carton, 6PCS/20kg/0.07cmb/Cnt
Specification
27.6*17.5*9.5cm
Trademark
CARSPA or OEM
Origin
Zhejiang, China
HS Code
8504409999
Production Capacity
500000PCS/Year

Product Description

12V/24V 60A 7 stage  Automatic Car RV battery Charger  for AGM GEL WET Rechargeable  Battery Charger With LCD
12V/24V 60A 7 stage Automatic Car RV battery Charger for AGM GEL WET Rechargeable Battery Charger





Features:

1.LED digital display : U-I-C-P

U:battery voltage  I:charge current   C:7 charging stage code  P:over heat protection

2.LED indicators : AGM /GEL /Lithium battery

3.AGM/GEL/Lithium  battery charge mode selection

4.Numerious protection function: overheat, over charge, short circuit, soft start, internal temperature compensation, reverse polarity, over charge protection.

5.7 Stage automatically charging:


C-1-Desulphation: The desulphation stage may break down sulphation that occurs in batteries that have been left flat for extended periods of time, returning them back to full charge. Sulphation occurs when lead-sulphate hardens and clogs up the battery cells.

C-2-Soft-Start:A preliminary charge processes that gently introduces power to the battery.This protects the battery and increases battery life.

C-3-Bulk(Constant Current):Bulk mode charges the battery at the maximum rate (constant current)putting a large amount of power into the battery in a short amount of time.This stage will charge the battery to approximately 80%,until the voltage reaches 14.4 volts for 12V battery or 28.8volts for 24V charger.

C-4-Absortion(Constant Voltage):The charge rate slows down so the battery can absorb more power and reach 100% charge. The voltage remains at a constant 14.4 volts for 12V charger or 28.8 volts for 24V charge while the current is gradually reduced until no more power can be added without over-charging the battery.

C-5-Battery Test:An automatically battery test is conducted immediately after the absorption stage. The test monitors the voltage for 90 seconds to determine if the charge was successful.

C-6-Recondition:The battery reconditioning function is initiated automatically in the case that the battery fails the battery test (stage 5). Failing the battery test indicates that the absorption stage was unable to fully charge the battery. The recondition mode will then begin to introduce a low constant current for a period of 4 hours. Then the charger will go into the float charging mode. This recondition stage can recover batteries from a deeply discharged state increasing performance and battery life.

C-7-Float:The float stage maintains the battery at 100% charge without overcharging or damaging the battery. This means the charger can be left connected to the battery indefinitely.







Specification:

Model EBC12/24-30 EBC12/24-40 EBC12/24-50 EBC12/24-60
Input voltage AC220V(190-265V)
Output voltage 12V/24V
LED digital display in turn(after 60s go into sleep mode) U:battery voltage
I:charging current
P: over heat protection
C: code for 7 charging stage
Absoption (constant voltage) AGM:14.4V/28.8VDC
GEL:14.6V/29.2VDC
Float charging current AGM:13.8V/27.6VDC
GEL:14V/28VDC
Max.charging current 30A/15A 40A/20A 50A/25A 60A/30A
Protection function Reverse polarity,output short circuit,over current,over voltage,overload,over heat
Charging way Automatic 7 stage charging:Desulphation,soft start,bulk,absorption,battery test,recondition and float
LED display charging voltage, charging current , charging stage, 50%current, 100% currenyt. AGM battery, GEL battery , switching power supply
Working temperature 65ºC±5ºC
Cooling fan  Temerature controlled automatically
Temp.compensation -3~3.5nV/cell*Tem.±10%
Battery type GEL and AGM battery and lithium battery (customized)
Efficiency 80%
Battery selection 50% current or 100% current
LED indicator/button setting
Packing Gift box
AC fuse 6A 6A 6A 6A
DC fuse 30A*2 40A*2 40A*2 40A*2
Qty/ctn 6pcs
Dimension(L*W*H) 22.6*17.5*9.5cm
Certification CE,RoHS,SONCAP





12V/24V 60A 7 stage Automatic Car RV battery Charger for AGM GEL WET Rechargeable Battery Charger

12V/24V 60A 7 stage Automatic Car RV battery Charger for AGM GEL WET Rechargeable Battery Charger
12V/24V 60A 7 stage Automatic Car RV battery Charger for AGM GEL WET Rechargeable Battery Charger
`
12V/24V 60A 7 stage Automatic Car RV battery Charger for AGM GEL WET Rechargeable Battery Charger
