Product Description
Benergy Charger is specially for Lithium Ion Battery pack. The working mode of our charger is CC/CV (constant current/constant voltage) mode.
72V 25A Parameter Table:
| Product Type | Lithium Iron Phosphate Battery Charger |
| Brand Name | Benergy |
| For Battery Pack | 72V (24S) Lifepo4 Battery Packs |
| Charge Voltage | 87.6V |
| Charge current | 25A |
| Size | 282×168×90(mm) (L,W, H) |
| Weight | 3800g±50g |
| AC input wide voltage range | AC90V~264V |
| Input voltage frequency range | 40~70Hz |
| With APFC function, power factor | ≥ 0.98 |
| Soft switching technology, overall efficiency | ≥ 93.0% |
| IP range | IP67 |
| Working temperature | -40ºC~ +60ºC |
| Storage temperature | -55ºC~ +100ºC |
| CAN BUS communication | Can support. (Please remark if you need when place the order) |
| Charge Mode | CC/CV (Continuous current/Continuous Voltage) |
| Noise | ≤ 45dB |
| Warranty | 1 Year |
| OEM/ODM | Yes(Accepted) |
Detail sizes
Main protection function:
1. Overheat protection:
When the internal temperature of the charger exceeds 80 ºC, the current of the charger automatically decreases. When the temperature exceeds 85ºC, the charger shuts down for protection. When the temperature drops, charging automatically resumes.
2. Short circuit protection:
When the output is short circuited, the charger automatically turns off the output. After troubleshooting, reconnecting the battery can restore charging.
3. Battery reverse connection protection:
When the battery is connected in reverse, the internal circuit of the charger will automatically disconnect from the battery, and if not charged, it will not damage the charger.
4. Input undervoltage and overvoltage protection:
When the input voltage is below 90V or above 264V, the charger protection shuts down and automatically resumes operation after the voltage is normal.
5. Fully charged automatic shutdown: Automatically shuts down when fully charged.
Other chargers 2000W
2KW FULLY SEALED CHARGER
| Specifications and models | Input Voltage Range | Rated Output Voltage | Max Output voltage | Max Output Current |
| BCZ2-2445A | AC 180~264V | 24V | 33.0V | 45A |
| BCZ2-4835A | AC 180~264V | 48V | 66.0V | 35A |
| BCZ2-6030A | AC 180~264V | 60V | 82.5V | 30A |
| BCZ2-7225A | AC 180~264V | 72V | 99.0V | 25A |
| BCZ2-4825C | AC 90~264V | 48V | 66.0V | 25A |
| BCZ2-6020C | AC 90~264V | 60V | 82.5V | 20A |
| BCZ2-7218C | AC 90~264V | 72V | 99.0V | 18A |
Input connector (selectable):
Input connector for your selection:
Details.
Certificate
Packages
Applications
Shipping
Benergy can arrange shipping for you. Shipping way can be by sea, by air,by UPS/DHL/Fedex delivery to your door.
FAQ:
Q1: Is the charger water proof.
A1: Yes, our chargers are IP76. Fully water proof.
Q2: Do you have Li-NCM charger?
A2: Yes, we also have other chargers which can charge Li-NCM batteries, but pls make sure which type battery pack need to charge when you select the charger.
Q3: What is delivery time if we place an order?
A3: It depends order quantities. Usually, we can deliver goods within 10 -15 working days for small orders, for more QTY. order, let's confirm when you place offical order.
Q.What is your warranty?
A5:We provide 1 year quality warranty for the charger. If need longer warranty, price will be different.
