Agv 3.2V 200ah Lithium Ion/Li-ion Battery Electric Vehicle Battery for 24V 36V 48V 60V Electric Scooter UPS Marine Golf Cart RV

AGV 3.2V 200Ah Lithium Ion Battery for Electric Vehicles. Factory direct supplier for 24V-60V applications. Ideal for scooters, marine, golf carts, and UPS.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
LFP-230
Electrolyte
Li-ion
Usage
RV/Solar System/Electric Vehicle
Nominal Voltage
3.2V
Other Name
LiFePO4(Lithium Iron Phosphate)
Screw Size
M6
Weight
3.5kg
Shell Material
Plastic(Grey or Blue)
Cycle Life (80%Dod)
4000
Production Date
2022
Quality Level
New Grade a
Charging Temperature
0~45degree Celsius
Discharging Temperature
-20~55degree Celsius
Warranty
18 Months
Transport Package
Export Package
Specification
174mm x 53.72mm x 207.2mm
Trademark
CALB
Origin
P. R. China
HS Code
8507600010
Production Capacity
50000 PCS/Month

Product Description

Agv 3.2V 200ah Calb Lithium Ion LiFePO4 Cell Storage Battery Electric Vehicle Battery for 24V 36V 48V 60V Electric Scooter UPS Marine Golf Cart RV
  Title China high quality Lithium Ion LiFePO4 Cell Storage Battery Electric Vehicle Battery for UPS Marine Golf Cart RV
  206/230Ah
Port of Loding Shen zhen/Shanghai

Honours
Top quality,we work with world's top 500 company
20000 SQM&More than 1000 workers for production
Giant warehouse available for customer


Services



1.We offer OEM/ODM services with our professional team.
2.We have own molding workshop.
3.Low MOQ,more friendly for different customer.
4.All email,we will give reply within 8 hours.
5.About samples,we will produce in short time.
6.We have own transportation partner,it will make easy to delivery battery.
Cell type                    LFP
Nominal Voltage 3.2V
Nominal Capacity 205Ah
End of charge Voltage 3.65V
End of charge Current 230mA
Internal Resistance 0.1-0.5mΩ
End of discharge Voltage 2.5V
Charge Method 0.2C (0.5A) CC/CV
Max.Continuous discharge current              205A
Max.Pulse Discharge current(Long Pulse)          460A/3mins
Max. Pulse Discharge Current(Short Pulse)          690A/10S
Dimensions(mm) 174mm x 53.72mm x 207.2mm

Please contact us if you need specification.
Please tell us what terminal will you need?
Thank you!

Please Note:Our company did not provide Grade B or Used cheap Lifepo4 battery cells.
With B-grade quality batteries or old batteries, the assembled battery pack has a short life and is very susceptible to damage. Due to the long distance of international shipping, it can be very cumbersome to exchange returns in case of quality problems. And you'd be hard pressed to find cells with consistent internal resistance, voltage, and capacity to repair a battery pack.
It is highly recommended that customers with strict quality requirements use the new A-grade batteries
