16.8V 5A Laptop Li-ion 18650 Lithium Battery Charger China Supplier

Find reliable 16.8V 5A Laptop Li-ion 18650 Lithium Battery Charger China Supplier. We are a factory providing high-quality products at competitive prices.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
YS120
Output Current
0.1-5A Constant Current
Dimension
172*72.5*42.5mm
Rated Power
120W Max.
Use
Standard Battery
Transport Package
20PCS/CTN/42.5*42*20cm, , Inner PE Bag+White Box.
Trademark
Yingjiao
Origin
China

Product Description

16.8V 5A Laptop Li-ion 18650 Lithium Battery Charger China Supplier

Product Description
Battery charger Lithium battery charger
Model: YS120
Rated Power: 120W max.
Input: 100-240VAC 50/60Hz
Output Voltage: 16.8V /21V/ 25.2V/29.4V/ 33.6V/37.8V/42V/46.2V /50.4V /54.6V
Output Current: 0.1-5A Constant Current
Input current: 2.1A max.
Inrush Current: 65 Amps max. at 230VAC/50Hz,full load
Leakage Current: 0.25mA Max. at 264VAC input
No Load Power Consumption : <0.3W
Protections: Short Circuit /Over Current /Over Voltage
Short Circuit Protection (SCP): Protection to Zero Voltage
Over Voltage Protection (OVP): ≤Vout*150%
Over Current Protection (OCP): ≤Iout*150%
Working TEMP.: '-20-50°C
Working Humidity: 5%-90% RH non-condensing
Storage TEMP.,Humidity and altitude: ,-40 ~+70°C ambient temperature and a 5% to 95% relative humidity range throughout an altitude range of -60 meters to +5000 meters AMSL.
Input wire EU,UK,US,AU plug option
Certificates and approvals: CE,EMC,RoHS,REACH
LVD EN 60335-1 /EN60335-2-29
EMI EMISSION: EN55014-1/EN55014-2
EN61000-3-2
EN61000-3-3
MTBF: 100000 hours minimum at full load at 25 C ambient
Dimension: 172*72.5*42.5mm
Weight: 590g
Packing: 20PCS/CTN, 42.5*42*20CM



Details:

Model: YS120-1685000 YS120-2104000 YS120-2524000 YS120-2943000 YS120-3363000 YS120-3783000
DC Voltage: 16.8V 21V 25.2V 29.4V 33.6V 37.8V
Rated Current: 5000mA 4000mA 4000mA 3000mA 3000mA 3000mA
Current Range: 0-5000mA 0-4000mA 0-4000mA 0-3000mA 0-3000mA 0-3000mA
Rated Power: 84W 84W 100.8W 88.2W 100.8W 113.4W
Voltage Range: ±5%
Line Regulation: ±3%
LED indicator Red is charging ,Green is idle and full charged.
There will be a continous float charging current 150mA after full charged .
Setup,Rise,Hold up time: 1000ms,50ms,16ms at full load
