Basic Info.
Model NO.
LWC22K-380S380-W
Origin
China
Product Description
Product Features:
Body Size: 370x252x158mm
Weight: <25KG
Cooling method: Liquid cooled, flow rate≥10L/min
IPrating : IP67
Support on-line upgrading and fault diagnosisCompatible with single and three phase charging station
Full digital software design, Redundant protection function design
Main Technical Parameters
| Items | Technical Specification | Remarks |
| Output Power | 22kW | Support single phase 6.6kW |
| Input voltage | Three phase: 304-456Vac (L-L, three phase four lines) | Single phase input; 175-265VAC |
| Output voltage | 200-450Vdc | |
| Max output current | 64A | Single phase input:20A |
| Auxiliary power supply | 9-32Vdc | VCC |
| Eff. | ≥94% | @nominal voltage |
| Voltage accuracy | ±1% | |
| Current accuracy | ±3% | |
| Low voltage wake-up | 12/24Vdc&200mAmax (WAKE_UP signal) | Wake up BMS/VCU |
| Wake-up mode | AC/CC/CP | Support book charging |
| Communication | CAN-BUS | |
| Static current | ≤2mA | Sleep mode/ consume battery current at stop status |
| Working temp. | -40-85ºC | |
| EMC | GBT 18387: 2008, EN 55022 | |
| Protection | Input OVP, UVP, output OVP, UVP, OTP, OCP, output short circuit protection, communication fault protection | |
